TOP quality 100w CO2 laser engraving machine

Model No.:ZC-DK-CO2

Brand:Zhongcan

Application:Laser Engraving

Applied Material:Acrylic, Crytal, Glass, Leather, Mdf, Paper, Plastic, Plexiglax, Plywood, Wood, Stone, Rubber

Engraving Area:Other

Laser Type:Co2

Support Graphic Format:Plt, Dxf, Bmp, Dst, Dwg, Las, Dxp, Ai

Old And New:New

Whether CNC:Yes

Cooling Method:Water Cooling

Place Of Origin:China

Certification:Sgs, Iso, Ce, Gs, Ccc

Industrial Laser Brand:Ii-Vi

Servo Motor Brand:Fuji

Linear Guide Brand:Pmi

Laser Machine Control System Brand:Ruida

Optical Lens Brand:Ii-Vi

Core Selling Point:Easy To Operate

Warranty Period:3 Years

Applicable Industry:Hotels, Garment Shops, Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Printing Shops, Food Shop, Retail, Home Use, Restaurant, Farms, Food &Amp; Beverage Factory, Construction Works, Energy &Amp; Mining, Food &Amp; Beverage Shops, Advertising Company

Out-of-warranty Service:Video Technical Support, Online Support, Spare Parts, Field Maintenance And Repair Service

Where To Provide Local Services (in Which Countries Are There Overseas Service Outlets):Egypt, Philippines, Spain, Chile, Ukraine, Uae, Thailand, Brazil, Canada, Kyrgyzstan, Nigeria, Colombia, Japan, Peru, Turkey, United Kingdom, Saudi Arabia, Malaysia, Algeria, Uzbekistan, Sri Lanka, Australia, Indonesia, United States, Italy, Pakistan, Morocco, Romania, Tajikistan, Bangladesh, Kenya, India, France, Germany, Mexico, Argentina, South Africa, Kazakhstan, South Korea, Russia, Viet Nam

Showroom Location (in Which Countries Are There Sample Rooms Overseas):Egypt, Philippines, Spain, Algeria, Nigeria, Uzbekistan, Sri Lanka, Thailand, Brazil, Canada, Turkey, Peru, Morocco, Romania, Tajikistan, Japan, Bangladesh, Kenya, Saudi Arabia, United Kingdom, United States, Indonesia, Argentina, South Africa, Malaysia, Australia, South Korea, Pakistan, Italy, France, India, Chile, Ukraine, Kazakhstan, Uae, Mexico, Germany, Viet Nam, Russia, Colombia, Kyrgyzstan

Mechanical Test Report:Provided

Video Factory Inspection:Provided

Marketing Type:New Product 2020

Core Components:Motor

Condition:New

Machinery Test Report:Provided

Place Of Origin:Shandong, China

Marketing Type:New Product 2021

Brand Name:Zhongcan

Application:Laser Engraving

CNC Or Not:Yes

Repetition Precision:0.001mm

Engraving Speed:500mm/S

Positioning Way:Red Light

Cutting Speed:0~30000mm/Min

Marking Depth:25mm

Laser Source:Yongli/Reci/Efr

Cutting Area:1300*900mm

Warranty Of Core Components:3 Year

Cooling Style:Air/Water Cooling

Core Component Warranty Period:3 Years

Weight (KG):380 Kg

Selling Units	:	Set/Sets
Package Type	:	Standard Sea Freight Package/Non steaming wooden box packing
Picture Example	:

TOP quality 100w CO2 laser engraving machine

Zhongcan Technology Co.,Ltd. is a high development manufacture engaged in research , development , production and service of CO2 Laser Engraver , Laser Cutting Machine , Fiber Laser Marking Machine  covering the line of arts and crafts processing , advertising , signs , University education ,medical industry , clothing processing , building models , wood furniture ,acrylic cutting , image carving and other industries .Based on China CCPIT and China Business Bureau support , we won lots of awards in exporting and Technological innovation . Our Company was founded in the year of 2012 , has more than 100 employees , and factory area over 2000 square.As a Leader of China B2B , B2C , our products are sold out to America , Europe,Middle East and South Asia.We have many agents and warehouses . Let us cooperate together , to work out best solutions for you to expand your business

Model	ZC-DK-CO2
Laser Type	CO2 sealed laser tube,water-cooled 10.6um
Laser Power	60W/80W/100W/130W/150W/180
Marking Area	1300*900mm 51inch*35inch
Engraving speed	0-60000mm/min / 0-2362in/min
Cutting Speed	0-30000mm/min / 0-1181in/min
Repetition Precision	0.001mm
Laser Source	Reci/Yongli
Total Power	220V±10% /50HZ 110V±10%//60HZ
Supported Windows	All Windows
Supported Format	PLT/AI/DXF/BMP/DST/DWG/LAS
Min. shaping character	Letter 1.0 x 1.0mm
Highest Scanning Precision:	2500DPI
Machine size	1850*1310*1140mm 72.8*51.5*44.8inch
package size	2000*1470*1330mm 78.7*57.8*44.8inch
Net Weight /Gross weight	380KGS/500KGS
Optional part	Up and down table, rotary attachment, red light pointer, auto focus system

01 CO2 Laser Tube

Adopt the new high-efficiency CO2 laser tube of RECI, the 100W CO2 laser tube can reach a peak of 122W. The laser beam is more stable and the life of the laser tube can exceed 10,000 hours.

02 Adjustable Laser Head

The aluminum alloy adjustable laser head is lighter than other metal laser heads, which can minimize the inertia error when the laser head moves.” The structure is simple, the operation is convenient, the laser device is stable,and the maintenance cost is low.

03

Taiwan HIWIN Guide Slider

Taiwan Hiwin square guide rails are made of high-strength special steel to ensure that the laser machine does not deform continuously for a long time. Improve laser engraving and cutting accuracy and extend the working life of the machine.

04

Perfectly Tidy Power Supply System

The power supply system of the whole machine is strictly in accordance with international standards. Different control power signal lines adopt separate routing design, and the whole is clean and tidy, avoiding electromagnetic interference between various types of signal lines.

05

accessory

Laser tube Power cord Data line Focal length ruler Tobacco tube Encryption lock Chimney Focal length ruler Toolbox/CD (software/tutorial/instruction)
